General Information

• Model Identifier: KM 8565 FL

• Manufacturer Product Code: 12911440

• EAN Number: 4002516951292

• Old Material Number: 26I85651D

• Marketing Class: Gold

Heating Type

• Heating Type: Induction

Construction Type

• Independent of Cooker: Yes

Design

• Elegant Ceramic Glass Surface: Yes

• Ceramic Surface Colour: Black

• Flush-Fit Installation: Yes

• Surface-Mounted Installation: Yes

Cooking Zone Details

• Number of Cooking Zones: 4

• Number of Cooking Areas: 2

• Maximum Number of Pans: 4

PowerFlex Cooking Zones

• Number of PowerFlex Cooking Zones: 4

• Type: PowerFlex Cooking Zone

• Size: Ø 120–230 mm

• Maximum Power: 2100 W

• Maximum Booster Power: 3650 W

1st Cooking Zone / Cooking Area

• Position: Left

• Type: PowerFlex Bridge

• Size: 230 x 390 mm

• Maximum Power: 4200 W

• Maximum Booster Power: 7360 W

2nd Cooking Zone / Cooking Area

• Position: Right

• Type: PowerFlex Bridge

• Size: 230 x 390 mm

• Maximum Power: 4200 W

• Maximum Booster Power: 7360 W

User Convenience

• Networking with Miele@home: Yes

• Con@ctivity: Yes

• Pan and Pan Size Recognition: Yes

• M Sense Ready: Yes

• Operation: MultiSlide Sensor Controls

• Display Colour: Yellow

• Intelligent Pan Recognition: Yes

• Stop & Go Function: Yes

• Wipe Protection: Yes

• Recall Function: Yes

• Minute Minder: Yes

• Safety Switch-Off: Yes

• Auto Heat-Up: Yes

• Keeping Warm: Yes

• Individual Setting Options, e.g. Buzzers: Yes

• Assistance Programmes: Yes

Efficiency and Sustainability

• Power Rating in Off Mode: 0.3 W

• Power Rating in Standby Mode: 0.8 W

• Power Rating in Networked Standby: 2.0 W

• Time Until Automatic Switch to Off Mode: 10 min

• Time Until Automatic Switch to Standby Mode: 10 min

• Time Until Automatic Switch to Networked Standby: 10 min

Cleaning and Care

• Easy-to-Clean Ceramic Glass: Yes

Safety

• Safety Switch-Off: Yes

• Lock Function: Yes

• System Lock: Yes

• Integrated Cooling Fan: Yes

• Overheating Protection: Yes

• Residual Heat Indicator: Yes

Technical Data

• Dimensions (H x W x D): 51 x 620 x 520 mm

• Width: 620 mm

• Height: 51 mm

• Depth: 520 mm

• Cut-Out Dimensions for Surface-Mounted Installation (W x D): 600 x 500 mm

• Cut-Out Dimensions for Flush-Fit Installation (W x D): 600/624 x 500/524 mm

• Casing Height Including Connection Box: 51 mm

• Cut-Out Width for Surface-Mounted Installation: 600 mm

• Cut-Out Depth for Surface-Mounted Installation: 500 mm

• Internal Cut-Out Width for Flush-Fit Installation: 600 mm

• Internal Cut-Out Depth for Flush-Fit Installation: 500 mm

• External Cut-Out Width for Flush-Fit Installation: 624 mm

• External Cut-Out Depth for Flush-Fit Installation: 524 mm

• Weight: 10 kg

• Total Connected Load: 7.36 kW

• Power Cable Length: 1.6 m

• Voltage: 230 V

• Frequency: 50–60 Hz

Accessories Included

• Power Cable: Yes
